is-Engine

is::Engine (Infinity Solutions::Engine) 4.0.3

Open source C++ framework which uses the mechanisms of SFML 2 and which also allows to develop with several libraries at the same time (SDL 2, Emscripten) in order to easily export your games / applications on the Nintendo Switch, Web (HTML 5), Mobile and PC (Windows, Linux, macOS).

Contents

• Features
• What's new in this version
• Extras
• Game Engine User Guide and Youtube Tutorial
• Example of a project created with the engine
• Hello Scene Example
• Prerequisites
• How to use is::Engine with the different development tools
• Description of the project structure
• How to update an is::Engine project
• Special things to know about the engine
• How to activate the use of Admob
• Contribute

Features

• Run SFML game / application on SDL 2 (Like an Emulator)
• Language manager (English and French language support by default)
• Scene System
• Automatic management of a window
• Multi support for development tools (Nintendo-Switch, Android Studio, Qt, CMake, Emscripten, Visual Studio Code, Code::Block, Visual Studio
• is::LibConnect
• Web Push Notification
• SDM (Step and Draw Manager)
• GSM (Game Sound Manager)
• GRM (Graphics Resources Manager)
• CFF (CMake Files Fusion)
• TMX Lite
• TMX Loader (Old version)
• Entity system
• Object Event System
• Button System
• Background System
• Game Slider
• Sprite Animation
• Basic collision engine
• 2D physic engine (Box 2D)
• Message Box System (Modifiable appearance via Sprites and Font)
• Dialog Box System (as for RPG games)
• [Windows, Linux] Tiny File Dialogs to manage the dialog boxes of type: Message, File Save, Load File, Folder Selection
• Game Configuration System (sound, music, language, keyboard key, file path, ...)
• Game Save System
• [Android] Virtual Game Pad with 6 keys (multi directional cross and A - B button)
• [Android] Virtual Game Pad Configuration (Adjust Position, transparency, ...)
• [Android] Show Ad Banner
• [Android] Show Reward Video

What's new in this version

• Support for sf::RenderTexture in SDL 2
• Improved SFML simulator system with SDL 2
• Bug fixes

4.0.2

• Using Visual Studio and SDL 2 to develop with SFML.
• Bug Fixes

4.0.1

• Nintendo Switch Support
• The Demo and tutorials are compatible with the Nintendo Switch.
• Visual Studio 2022 can be used with all projects.
• Vertex Arrays support (Simulation with SDL 2).
  When you want to use a texture with vertices, you must set the optional parameter useWithVertices to true in the loadFromFile() function, which is necessary when using SFML with SDL2.

 sf::Texture texture; texture.loadFromFile("image.png", true);

Extras

• Here is a Web Game : Arkanoid created thanks to the game engine tutorial.
  It's a Web Game so it's playable on PC and mobile.

• The engine comes with a Demo (2D Platform Game) that uses only the functions of the engine, in order to show you its power and how to use it. Now imagine what you can do when you use Box 2D and the other tools!

• Example Pack that show how to use the various features of the game engine.

Game Engine User Guide and Youtube Tutorial

• English version
• French version
• Youtube tutorial : How to import an SFML project into is::Engine
• Youtube tutorial : How to create a game (Arkanoid) with the game engine

Example of a project created with the engine

• I Can Transform
• GravytX The Gravytoid

Hello Scene Example

Here is an example code of a Scene (the place where the game objects come to life). In less than 50 lines of code, the engine allows to:

• Change the language of the game (English / French)
• Display an RPG type message with interaction
• Animate an object with the possibility of interacting with it (by clicking / touching it)
• Load resources (Textures, Music)
• Play music
• Display a background that scrolls vertically and horizontally with a speed
• Manages the display depth of each object
• Automatically manages the game window (closing confirmation, events, ...)
• Change the background color of the window (scene color)

class HelloScene : public is::GameDisplay {
public: HelloScene(is::GameSystemExtended &gameSysExt): GameDisplay(gameSysExt, sf::Color::White /* => scene color*/) {} void loadResources() { m_gameSysExt.m_gameLanguage = is::lang::ENGLISH; // set default game language // uncomment to change English language in French // m_gameSysExt.m_gameLanguage = is::lang::FRANCAIS; // load font and texture GameDisplay::loadParentResources(); // allows to load system resource (very important never forgot to call him) GRMaddTexture("hello_world", is::GameConfig::SPRITES_DIR + "hello_world.png"); auto &texBg = GRMaddTexture("background", is::GameConfig::TILES_DIR + "background.png"); auto &texDialog = GRMaddTexture("dialog_box", is::GameConfig::GUI_DIR + "dialog_box.png"); // add a background to the position x = 0, y = 0 which will fill the scene and which will be scrolled (scrolling speed = 0.5) SDMaddSceneObject(std::make_shared<is::Background>(texBg, 0.f, 0.f, this, 0.5f, -0.5f, false, false)); // add an object at position x = 0, y = 0 which will be updated and displayed in the scene SDMaddSceneObject(std::make_shared<HelloWorld>(0.f, 0.f, this)); // add RPG style game dialog auto gameDialog = std::make_shared<is::GameDialog>(texDialog, GRMgetFont("font_msg"), this); gameDialog->setDepth(-2); // the display depth (make it appear on all objects. The object with the smallest value appears on the others) gameDialog->setDialog(is::GameDialog::DialogIndex::DIALOG_HELLO); // set the corresponding dialog (See GameDialog.h and GameLanguage.h for more details on creating a message for dialogue) SDMaddSceneObject(gameDialog); GSMaddSound("game_music", is::GameConfig::MUSIC_DIR + "game_music.wav"); // add music GSMplaySound("game_music"); // play music }
};

Prerequisites

• SFML Library (2.4 +)
• SDL 2 (2.0.12 +)
• GCC Compiler (7.3 +)

How to use is::Engine with the different development tools:

Nintendo Switch

This project uses the template of carstene1ns.

1. Prerequisites

• DevkitPro with MSYS2

Very important

• Not affiliated with Nintendo.
• All your source files (only .cpp or .c) must be located in the root of the cpp folder otherwise the compiler will not find them!
• The Switch uses the same touch functions as Android.
• The engine has been configured so that you can use the PC functions keyIsPressed(is::GameConfig::KEY_UP) or keyIsPressed(is::GameConfig::KEY_A), etc. on the Switch.

2. Installation

Windows

1. Download devkitPro and install it in C:/devkitPro/.
2. During installation:

• Check "devkitA64" (for Switch)
• Check "MSYS2 Base System"
• Check "portlibs" if available

1. Once installed, open the MSYS2 terminal (C:\devkitPro\msys2\msys2.exe)
2. Enter these commands in the console to download libraries:

pacman -Syu
pacman -S switch-sdl2 switch-sdl2_image switch-sdl2_mixer switch-sdl2_net switch-sdl2_ttf

1. Move the is-Engine project to your C:/ (C:/is-Engine).
2. Run the file copy_assets.cmd so that it transfers your resources which are in the assets folder to romfs (this folder will be created when executing the copy_assets.cmd file) necessary for the compilation.
3. Enter these commands in the console:

cd c:/is-Engine/app/src/main/
make

If all goes well you will have a main.nro file in the main folder that you can launch via Nintendo Switch emulators (Yuzu, Ryujinx, ...).

Enjoy!

Android Studio

This project uses the template of Georgik and Lauchmelder23.

1. Prerequisites

• Android Studio (4.0.1 +)
• Android SDK and NDK (r20b)

Very important

• On Android SFML games run with SDL library. If you want to use SDL functions in your source code, use the IS_ENGINE_SDL_2 macro.
• The audio format supported at the moment is .WAV
• Your help to improve the engine will be welcome!
• Please read this.

2. Installation

Windows

1. Download Android Studio 3.x (recommended version 4.0.1).
2. Download the Android SDK and install it in C:/Android/SDK.
3. Download Android NDK android-ndk-r20b-windows-x86_64 and create a folder on your disk as follows C:/Android/NDK then extract the contents of the zip in this folder.
4. Set the environment variable ANDROID_NDK with the path C:/Android/NDK.
5. Move the is-Engine project to your C:/ (C:/is-Engine).
6. Open the is-Engine folder with Android Studio and start the compilation.

If all goes well you will have a Hello World Screen on your Android emulator.

Enjoy!

2. How to replace the package name (com.author.isengine) of the application

• Follow these steps carefully. A single error and the application will crash wonderfully when launching on emulator / mobile!

1. Replace this line in the gradle.app file.
2. Replace this line in the AndroidManifest.xml file.
3. Replace this line in the SDLActivity.java file.
4. Replace the abresence com/author/isengine in which is the file SDLActivity.java that you have just modified at the top by yours (example com/yourname/yourgamename).
5. Replace this part ..._ com_author_isengine _... of line 20 and 23 in the file SDL_android_main.c by yours (example com_yourname_yourgamename).
6. Replace this part ..._ com_author_isengine _... on the 23 lines of the file SDL_android.c by yours (example com_yourname_yourgamename).

• I strongly advise you to use the replace function of your text editor (on Notepad++ we use Ctrl + F + Replace option).

1. Replace this line in the GameConfig.h file.

• Note that this part is only required if you want to use the game engine data save / load functions.

3. Adding Source Files

• So that Android Studio can detect your source files (.cpp) you must include them in the app_src.cmake or isengine.cmake file which is located in the is-Engine/app/src/main/cmake location.

4. Application location

• The application can be found in is-Engine/app/build/outputs/apk.

Web (HTML 5 - CSS 3)

If you want to make your SFML project compatible with the Web (Be able to run it in a web browser), please watch this video tutorial.
Now you can put texts and geometric shapes (Rectangle, Circle) in Outline on the Web (It was not available in the old versions)!

1. Prerequisites
